LOA 25.02 m Beam 8.41 m Draft 3.27 m Bollard Pull : 31 tons Speed : 12 knots Engines : 1 x Alpha / Echevarria Construcciones SA 14V23LU, 1,493 kw, 800 rpm, Propellers 1 Controllable Pitch (Center) Built in year 1984 Class : Registro Italiano Navale Flag : Spain (CSR) Gross Tonnage of 169 and Nett Tonnage of 36 Deadweight : 81 metric tonnes... read more

The ASD 25m/40t tugboat is a modern twin Z-drive (azimuth rudder thrusters) in nozzles driven tugs, suitable for terminal ship assist and escort operations. Designed and equipped with high quality marine components and equipments. Tugboat is designed to provide effective escort, ship-assist works with Fi-Fi ability. The tug can be configured as a coastal voyage with full accommodation. Specifications: Length (LOA) 25.50m Beam (moulded) 8.80m Depth to main deck (moulded) 4.00m Draft (maximum) 3.50m Displacement tonnage 410t... read more

Dimentions: Small Tug boat / Line handiling tug boat Lenght: 15meter Beam: 5.80meter Draft: 1.60meter OPTION 1 (16 TON BOLLARD PULL) Main Engines : VOLVO D16 750hp@1900rpm Power Total: 1500hp Gearbox: Twindisc Crane: Heila Classification: BV Bollard pull : 16TON BOLLARD PULL OPTION 2 (13-14 TON BOLLARD PULL) Main Engines : VOLVO D13 550hp@1900rpm Power Total: 1100hp Gearbox: Twindisc 5114 Crane: heila (optional) Classification: BV Bollard pull : 13-14TON BOLLARD PULL Navifation equipment: Raymarine radar Raymarine VHF Raymarine Echosounder Raymarine GPS Raymar... read more

Dimensions Length overall (Hull) = 18.50 meters Length between perpendicular = 16.00 meters Breadth moulded = 7.00 meters H = 2.80 meters D = 2.00 meters Speed = 10.00 kn GT =... read more

LOA 38 m Beam 12.81 m Draft 6.64 m Bollard Pull : 42 tons Speed : 10.5 knots Engines : 2 x EMD (Electro-Motive) / General Motors Em Div 12-645-E7B, 3,390 kw, Propellers 1 Voith-Schneider (Port Side) + 1 Voith-Schneider (Starboard) Built in year 1982 Class : American Bureau of Shipping Flag : Saint Kitts-Nevis Gross Tonnage of 499 and Nett Tonnage of 262 Deadweight : 480 metric tonnes... read more

LOA 41.86 m Beam 13.2 m Draft 6.05 m Bollard Pull : 62 tons Speed : 10 knots Engines : 2 x EMD (Electro-Motive) / General Motors Em Div 16-645-E7, 4,516 kw, Propellers 1 Fixed Pitch (Port Side) + 1 Fixed Pitch (Starboard) Built in year 1981 Flag : Saint Kitts-Nevis Gross Tonnage of 767 and Nett Tonnage of 230... read more

LOA 70.05 m Beam 14.95 m Draft 4.95 m Bollard Pull : 101 tons Dynamic Positioning of class : DP 2 Free Deck area about 500m² with a deck strength of 7.5 metric tonnes per square meter Capable of supplies of 800m³ Fuel Oils, 414m³ FW and 563m³ Liquid Mud Fire Fighting System of type FiFi 1 installed 1 Crane / Gear installed with a max lifting capacity of 5.9 tons 1 Crane / Gear installed with a max lifting capacity of 2.2 tons Built in year 2006 Design is : KCM 70M Class : Biro Klasifikasi Indonesia Flag : Indonesia Gross Tonnage of 1,986 and Nett Tonnage of 595 Deadweight : 1,673 ... read more

LOA 38.1 m Beam 10.6 m Draft 4.1 m Bollard Pull : 52 tons Speed : 12.5 knots Engines : 2 x Mitsubishi / Mitsubishi Heavy Industries S16R-MPTK, 2,760 kw, 1,650 rpm, Propellers 1 Fixed Pitch (Port Side) + 1 Fixed Pitch (Starboard) Auxiliaries Engines : 2 Cummins 240 kw, Bowthruster + No Sternthruster (1 Bow Tunnel thruster 200kw) Fire Fighting System installed Built in year 2007 Class : Biro Klasifikasi Indonesia Flag : Indonesia Gross Tonnage of 488 and Nett Tonnage of 146 Deadweight : 450 metric tonnes... read more

LOA 36.5 m Beam 10.4 m Draft 4.2 m Bollard Pull : 40 tons Speed : 11 knots Engines : 2 x Cummins / Cummins Diesel International KTA-50-M2, 2,388 kw, 1,800 rpm, Propellers 1 Fixed Pitch (Port Side) + 1 Fixed Pitch (Starboard) Auxiliaries Engines : 2 Cummins 270 kw Built in year 2012 Class : Registro Italiano Navale Flag : Indonesia Gross Tonnage of 448 and Nett Tonnage of 135 Deadweight : 400 metric tonnes... read more

LOA 37 m Beam 11.4 m Draft 4.05 m Bollard Pull : 50 tons Speed : 10 knots Engines : 2 x Cummins / Cummins Engine Co Ltd QSK60-M, 3,432 kw, 1,800 rpm, Propellers 1 Fixed Pitch (Port Side) + 1 Fixed Pitch (Starboard) Auxiliaries Engines : 2 Cummins 164 kw Built in year 2009 Design is : Conan Wu 37m Class : American Bureau of Shipping Flag : Bahrain Gross Tonnage of 472 and Nett Tonnage of 141 Deadweight : 338 metric tonnes... read more

LOA 28.22 m Beam 7.95 m Draft 2.43 m Bollard Pull : 15 tons Speed : 12 knots Engines : 2 x Deutz / Kloeckner-Humboldt-Deutz - GFR SBV6M536, 1,176 kw, 600 rpm, Propellers 1 Voith-Schneider (Port Side Aft) + 1 Voith-Schneider (Starboard Aft) Built in year 1968 Flag : Great Britain Gross Tonnage of 167 and Nett Tonnage of 50 Deadweight : 42 metric tonnes Ice strength... read more

Tugs are vessels that have a powerful propulsion system and are used for towing and pushing other vessels or large floatable objects. Generally familiar from the port sector as assistants tug, they increasingly tend to be used in the offshore market for towing and positioning pontoons, oil rigs and installation vessels. Furthermore, tugs are deployed for salvaging and dredging works. Basically, distinctions are made between tugboats equipped with a conventionally structured propulsion system (engine, gears, shaft-drive, propeller, rudder) and tugboats with a propeller capable of rotation... read more

30m Tugs (5 units) Builds completed ready for delivery, these 5, 30m tugs in BKI Class are open for inspection in Indonesia. Powered by twin Mitsubishi S6R-T2MTK3L engines (759kW each) with Kort Nozzles. Twin 62.5KVA gensets with 1 x 30KVA Emergency. LOA 30m x 8.3m. Total compliment for 18. Inspection is available in Indonesia by appointment. For a more detailed specification, please feel free to contact us.... read more

2008 47’ x 14.6’ x 5’ Steel Model Bow Tug New Price: $250,000 CDN Built in Port Lambton, Ontario This tugboat is truckable Gross tonnage: 18.14 tons Net tonnage: 13.61 tons Shell plate thickness: 3/16” Framing: Tubing Bulkheads: 3/16” Headroom: Wheelhouse – 6.5’, Cabin – 7’, Engine room – 7’ Engine: Detroit Diesel 8V71T, 350 hp Transmission: Twin Disc MG 5114 3:1 ratio Generator: 7.5kw Onan Shaft size: 3” Propeller: 38” x 32”, 4 blade, Nibral, RH Cruising speed: 8 knots Navigation equipment: VHF... read more

LOA 38 m Beam 11.8 m Draft 3.8 m Bollard Pull : 42 tons Free Deck area about 150m² with a deck strength of 5 metric tonnes per square meter Capable of supplies of 323m³ Fuel Oils and 157m³ FW Fire Fighting System installed Built in year 2006 Design is : KCM 38M Class : Bureau Veritas Flag : Malaysia Gross Tonnage of 499 and Nett Tonnage of 149 Deadweight : 415 metric tonnes 2 cabins with 1 berth 2 cabins with 2 berths 3 cabins with 4 berths Speed : 11 knots Engines : 2 x Cummins / Cummins Engine Co Inc KTA-50-M2, 2,388 kw, 1,800 rpm, Propellers 1 Fixed Pitch (Port Side) + 1 Fi... read more

LOA 28.5 m Beam 8.8 m Draft 4.61 m Bollard Pull : 30 tons Speed : 12 knots Engines : 2 x Deutz / Kloeckner-Humboldt-Deutz - GEU SBV6M628, 1,960 kw, 900 rpm, Propellers 1 Voith-Schneider (Port Side) + 1 Voith-Schneider (Starboard) Auxiliaries Engines : 2 MWM 60 kw Built in year 1991 Class : DNV Flag : Germany Gross Tonnage of 229 and Nett Tonnage of 68 Deadweight : 75 metric tonnes Ice classed 1D... read more

LOA 28 m Beam 9.6 m Draft 3.47 m Bollard Pull : 25 tons Speed : 10 knots Engines : 2 x Yanmar / Yanmar Diesel Engine Co Ltd M220-EN, 1,766 kw, 800 rpm, Propellers 1 Directional (Port Side) + 1 Directional (Starboard) Fire Fighting System of type FiFi 1 installed Built in year 1997 Class : American Bureau of Shipping Flag : Malaysia Gross Tonnage of 283 and Nett Tonnage of 85 Deadweight : 177 metric tonnes... read more

LOA 26.68 m Beam 8.23 m Draft 4.85 m Bollard Pull : 35 tons Speed : 12 knots Engines : 1 x Nohab / Nohab AB F212V, 1,941 kw, 825 rpm, Propellers 1 Controllable Pitch (Aft) Auxiliaries Engines : 1 x 152 kw, Bowthruster (1 Bow) Fire Fighting System installed 1 Crane / Gear installed with a max lifting capacity of 11 tons Built in year 1975 Class : DNV Flag : Norway Gross Tonnage of 181 and Nett Tonnage of 72 Ice classed 1C... read more

Almost complete, these tugs with appox 27t BP are available with short lead time for delivery. Classed RINA. LOA 28.6m x 8.5m Powered by twin XCW6200-10, 1100hp engines with twin 75kW aux. Compliement for 12. The vessel located in China is available for inspection on appointment. For a more detailed specification, please feel free to contact us.... read more

15M TUG BOAT Loyd T-184 CLASSIFICATION BV (Bureau Veritas) DIMENSIONS Length OA: 14.90 m Beam OA: 5.90 m Depth at sides: 3.00 m Draught Aft: 2.15 m Displacement: 90 tons TANK CAPACITIES Fuel-Oil: 14 m3 Fresh Water: 2.7 m3 Bilge Water: 1 m3 Grey Water: 1 m3 PERFORMANCES Bollard Pull: 20 ton Speed: 12 Knots PROPULSION SYSTEM Main Engines: 2x Yanmar 6AYM-WET Total Power: 1220 Kw Gear Boxes: REINTJES / WAF 364 L / Ratio : 1/5 Propulsion: FPP Bowthruster: Optional AUXILIARY EQUIPMENT Main Generator: 22 kWA Pumps: Bilge / GS / Fire DECK LAYOUT Anchor: 1x 70kg VHHP Chain:... read more
