3,200m3 Non-propelled Cutter Suction dredger Built Year: 2015 China Flag: China Class:ZC Navigation area:Costal Inspection Place:China Principal Dimensions and Characteristics Length of all:81.56m Length of Hull:62.7m Beam: 16.5m Molded Depth: 4m Molded Draft: 2.45m Dredging Depth:28m Suction diameter:800mm Discharge diameter:800mm Accommodation:25 Max. Discharge distance:3.5km Inboard Pump Characteristics Type:131-28-65 Water flow:10,000m3/h Revolution:410r/min Head:76m Q'ty:1set Manufacturer:Shijiazhuang,China Main Engine Type:12V280ZC Revolution:1000r/min Rate power:2650KW Manufa... read more

We are good backuped by Chinese first class shipyard who are specialized in dredger building.Any enquiry regarding hopper dredger or cutter suction dredger building will be appreciated. 1000m3 Trailing Suction Hopper Dredger Built:NEW ORDER Delivery time:15month Classification:CCS/BV Sea going Flag: China Principal Dimensions and Characteristics Length of all: 79.30m Beam: 14.00m Molded Depth: 5.30m Design Draft:4.30m Design dredging depth:15.00m Hopper capacity:1000-1400m3 Design speed:11knot F.O.C:6ton Crew:31 Endurance:15days Propeller Engine Power:2X1320KW S... read more

4,500m3 Non-propelled Cutter Suction Dredger Built:2008 China Flag: China Class:CCS Unrestricted Navigation Price idea: Inspection place:Tianjin,China Principal Dimensions and Characteristics Length of all: 92.40m Beam: 19.60m Molded Depth: 6.00m Design Draft: 4.20m Dredge depth:6-28m Discharge diameter & suction diameter of pipe:900mm Discharge distance:6km Crew:29 Inboard Pump Type:VOSTALMGVL 900-2300 Shaft Power:3800KW Revolution:292RPM Q'ty:2 set Maker:VOSTA Pump Engine Type:8DK-36 Rate power:4400KW Revolution:600r/min Q'ty:2 sets Maker:Dahaitsu JP Submerge pump Ty... read more

5500m3 Trailing Suction Hopper Dredger Built:2013 China Classification:CCS Sea going Flag: China Inspection place:Zhejiang Principal Dimensions and Characteristics Length of all: 105.00m Length BP: 95.20m Beam: 19.00m Molded Depth: 8.00m Design Draft:4.80m Design dredging depth:30.00m Design speed:11.5knot Crew:36 Propeller Engine Maker:Ningbo CSR Type:GN8320ZC2B/3B Power/speed:2500.00KW 600r/min Q'ty:2 sets Diesel generating set Maker:Weichai Chongqing Type:CW6200ZC-39 Rate power:540kw Rate speed:1000r/min Q'ty:3 sets Alternator Type:TFXW-450M6-H Power:450.00kw Rotation... read more

8,000m3 Trailing Suction Hopper Dredger Complete time:May 2012 China Classification:CCS Unrestricted Navigation Flag: China Inspection place:China Principal Dimensions and Characteristics Length of all: 134.00m Length of Hull: 119.20m Beam: 20.00m Molded Depth: 9.20m Design Draft:6.80m Hopper capacity:8100m3 DWT:11340T Inner diameter of suction pipe:800mm Design Speed: 13kn Dredging depth:35m Crew:36 Main Engine(driven shaft generator+CPP/Inboard pump) Manufacturer:Daihatsu JP Type:8DKM-36FL/F Power/speed:4500KW 600r/min Q'ty:2 sets Shaft generator Manufacturer:Shanghai Electrical ... read more

6000m3 Trailing Suction Hopper Dredger Built:June 2010 Inspect place:Tianjin China Classification:ZC Flag: China Principal Dimensions and Characteristics Length of all: 105.75m Length of Hull: 98.18m Beam: 18.80m Molded Deepth: 8.60m Design Draft:6.75m Hold capacity:5450.56m3 Design Speed: 12.2kn Dredging depth:35m Crew:32 Propeller Engine Wuxi Diesel Engine Factory Main Engine type:G8300ZC22B/G8300ZC23BH Power/speed:2426KW 630r/min Q'ty:2 sets Generator set Diesel Engine:Shandong Weifang Diesel Engine Factory Model:8170ZC Rate power:441kw Rate speed:1000r/min Q'ty:3 sets A... read more

6,000m3 Non-propelled Cutter Suction Dredger Delivery:18 month Flag: China Class:ZC Navigation area: Offshore Principal Dimensions and Characteristics Length of all: 116m Beam: 21m Molded Depth:5.3m Design Draft: 3.6m Dredge depth:30m Discharge distance:8km Inlet diameter:1200mm Outlet diameter:1100mm Crew:18 Inboard Pump Type:1000WN(2) Water flow:25,000m3/h Power:8419KW RPM:300 Head:78m Q'ty:1set Maker:Shijiazhuang Pump Factory Pump Engine Type:MAK8M601C Power:10,000KW RPM:428 Maker:MAK Germany Submerge pump(Diesel engine→Alternator→Pump motor→Submerge pump) ... read more
