Description

LOA 60 m
Beam 16 m
Draft 4.8 m
Bollard Pull : 70 tons

Dynamic Positioning of class : DP 1
Fire Fighting System of type FiFi 1 installed

Built in year 2010
Design is : Conan Wu 60m
Class : Bureau Veritas
Flag : Korea, South
Gross Tonnage of 1,731 and Nett Tonnage of 519

Deadweight : 1,689 metric tonnes

Speed : 10 knots
Engines : 2 x Niigata / Niigata Engineering Co Ltd 6L28HX, 3,676 kw, 750 rpm, Propellers 1 Z Type (Port Side) + 1 Z Type (Starboard)
Auxiliaries Engines : 3 Cummins 321 kw, Bowthruster + No Sternthruster (1 Bow Tunnel thruster 900kw)

Specifications

Engine(s)

2 x 3,676 kw, 750 rpm, Niigata / Niigata Engineering Co Ltd 6L28HX,
Propellers: 1 Z Type (Port Side) + 1 Z Type (Starboard)
