Description

Flag: Indonesia. Class: RINA & BKI. Builder: Wuhu Dajiang Shipyard. Main Engine: 2 x 1600 BHP @ 1800 RPM Cummins 50 KTA-M2. Speed: Approx. 12 knots (free running). Designer Bollard Pull: Approx. 40 tons. Propeller: 2 x Fixed pitch propeller with Kort nozzle. Fire Fighting & LSA: As per Solas. Aft Towing Winch. Towing Hook. Berths : 12-men (air conditioned), Cabin: 6 cabins

Specifications

Construction

LBP: 28m
Depth: 4.25m
GRT / NT: 248 tons / 74 tons

Equipment

Aft Towing Winch: 1 Electro-hydraulic ME 30 THTW, pull 300kn @ 5m/min pull 80kn @ 20m/min. Brake strength 100
Anchor Windlass: 2 X Anchor chain gysey 10m/min electric motor driven. 2 warping
drum
Anchor: 2 × 480 kg anchor & 19mm dia chains
Towing Hook: 1 x Changshu Shuangling 401 with remote pneumatic release
Stern Tubes: 2 x Oil lubricated with MK LL Lip seals

Navigation Equipment

Navtex: 1 x Nav 5plus

Engine(s)

Main Engine: 2 x 1600 BHP @ 1800 RPM Cummins 50 KTA-M2
Auxiliary Engine: 2 x Cummins 6CT8.3-D (M)
Generator: 2 x 99kW Stamford UCM 274E
Speed: Approx. 12 knots (free running)
Designer Bollard Pull: Approx. 40 tons
Propeller: 2 x Fixed pitch propeller with Kort nozzle

Electronics

GPS: 1 x Furuno GP-90
Radar: 1 x Furuno 1832
Echo Sounder: 1 x Furuno FEC 609
Magnetic Compass: 1 x Saura MR-150
Autopilot: 1 x Furuno Navpilot 500
MF / HF Radio: 1 x Icom M701 c/w DSC
Inmarsat-C: 1 x Mini M KVH Tracphone 252
Satoom C Tracking: 1 x KVH eTrac
Semi-Duplex Marine VHF: 2 x Icom M302
GMDSS EPIRB : 1 x McMurdo E3

Safety Equipment

Fire Fighting & LSA: As per Solas
Life Rafts: 2 x 15 men

Disclaimer

The particulars and specifications are supplied by the vendor and not SeaBoats. Such information has not been verified and may be incorrect. Please do not rely on particulars and specifications unless you have verified their accuracy.
