Description

Flag: Indonesia. Class: Rina & BKI. Builder: Wuhu Daijang Shipyard. Main Engine: 2 x 1600 BHP @ 1800 RPM Cummins 50 KTA-M2. Speed: Approx. 12 knots (free running). Designer Bollard Pull: Approx. 40 tons. Propeller: 2 x Fixed Pitch Propeller with Kort nozzle. Aft Towing Winch. Towing Hook. Berth: 12 men (air conditioned). Cabin: 6 cabins.

Specifications

Accommodation

Air-conditioned

Construction

Flag: Indonesia
LBP: 28m
Depth: 4.25m
GRT: 248 tons
NT: 74 tons

Equipment

Towing and Deck Equipment
Aft Towing Winch: 1 Electro-hydraulic ME 30 THTW, pull 300 kn @ 5m/min pull 80 kn @ 20m/min. Brake strength 100 ton. 700m x 44mm dia. Wire
Anchor Windlass: 2 x Anchor chain gysey 10m/min electric motor driven, 2 warping drum
Anchor : 2 x 480 kg Anchor & 19mm dia Chain
Towing Hook : 1 x Changshu Shuangling 40T with remote pneumatic release
Stern Tubes: 2 x Oil lubricated with MK LL Lip seals

Engine(s)

Main Engine: 2 x 1600 BHP @ 1800 RPM Cummins 50 KTA-M2
Auxiliary Engine: 2 x Cummins 50 KTA-M2
Generator: 2 x 99 kW Stamford UCM 274E
Speed: Approx. 12 knots (free running)
Designer Bollard Pull: Approx. 40 tons
Propeller: 2 x Fixed Pitch Propeller with Kort nozzle

Electronics

GPS: 1 x Furuno GP-90
Radar: 1 x Furuno 1832
Echo Sounder: 1 x Furuno FEC 609
Magnetic Compass: 1 x Saura MR-150
Navtex: 1 x Nav 5 plus
Autopilot: 1 x Furuno Navpilot 500
MF / HF Radio: 1 x Icom M701 c/w DSC
Inmarsat-C: 1 x Mini M KVH Tracphone 252
Satoom C Tracking: 1 x KVH eTrac
Semi-Duplex Marine VHF : 2 x Icom M302
GMDSS EPIRB: 1 x McMurdo E3

Safety Equipment

Fire Fighting & LSA: As per Solas
Life Rafts: 2 x 15 men

Disclaimer

The particulars and specifications are supplied by the vendor and not SeaBoats. Such information has not been verified and may be incorrect. Please do not rely on particulars and specifications unless you have verified their accuracy.
