| Global Work Boats | |
| Po Box 8160, Fremantle, WA, 6160, Australia | |
| Contact: | Stephen Collett |
| View All Global Work Boats Listings | |
| Status: | Available |
| Location: |
China [View Map] |
| Reference: | GWBOGUZ1047 |
Description
Built in 2004 in CCS class,Tug,AH,FIFI1, A1+A2 notation, this vessel is available ex China.
Powered by twin MaK 6M 25, 1896 kW engines with aux 2 x 1000, kW, 440V/3P/ 60Hz 2 x 270 kW, 440V/3P/ 60Hz 1 x 90 kW , 440/3P /60Hz.
Bow Thruster PP in Fixed Nozzle, Stern Thuster 450 kW, CPP , 7t Thrust
BP66.8t
Clear Deck Area 372m2 with 600t capacity.
Crane 1 x 5.5 T@11 m/min, crane 2 5 T @ 8 m, fixed boom
Fuel 527m3
Fresh Water 467m3
Drill/ Ballast water 482m3
Mud 177m3
Brine/Base oil 159m3
Accom for 26.
For a more detailed specification, please feel free to contact us.
Specifications
| Vessel type: | AHTS |
| Builder: | Other |
| Model: | AHTS |
| Constructed: | 2004 |
| Length over all: | 60m |
| Length at waterline: | 56.4m |
| Beam: | 16m |
