Description

LOA 69.6 m
Beam 38 m
Draft 3.05 m

Built in year 2017
Design is : Se-200LB
Class : American Bureau of Shipping
Flag : Saudi Arabia
Gross Tonnage of 7,659 and Nett Tonnage of 2,297

4 legs of 92m length for max water depth of 60m
Dynamic Positioning of class : DP 1
1 Crane / Gear installed with a max lifting capacity of 200 tons
1 Crane / Gear installed with a max lifting capacity of 20 tons
Free Deck area about 1,200m²
Deadweight : 1,461 metric tonnes
Heli Deck installed

Total passenger capacity 150 with 150 berths
10 cabins with 1 berth
14 cabins with 2 berths
28 cabins with 4 berths

Speed : 6 knots
Engines : 2 x Caterpillar / Caterpillar Inc 3516C-HD, 3,542 kw, 1,600 rpm, Propellers 1 Z Type (Port Side) + 1 Z Type (Starboard)
Auxiliaries Engines : 4 Cummins 1,097 kw, Bowthruster + No Sternthruster (1 Bow Tunnel thruster 500kw)

Specifications

Engine(s)

2 x 3,542 kw, 1,600 rpm, Caterpillar / Caterpillar Inc 3516C-HD,
Propellers: 1 Z Type (Port Side) + 1 Z Type (Starboard)
